Briggs & Stratton 8.75 TP Professional Series Engine 7/8" x 3-5/32" Vertical Shaft #125P02-0002

Briggs & StrattonSKU: 125P02-0002

Price:
Sale price$449.00
Stock:
Only 1 unit left

Description




Briggs & Stratton Professional Series


MODEL NUMBER:
125P02-0002

POWER OUTPUT:
8.75 Torque Power

SHAFT MOUNTING:
Vertical Shaft

SHAFT SIZE: (D x L)
7/8" x 3-5/32"

STARTER TYPE:
Recoil Starter

APPLICATION(S):
Walk Mower Engine

WEIGHT:
33 Lbs

REPLACES:
Universal replacement engine for Ransome, Bunton, Snapper,
MTD, Ariens, Murray, and other rotary mowers.
3100rpm Fixed Speed

WARRANTY:
2 Years Consumer / 1 Year Commercial
NOTES/FEATURES:

8.75 Gross Torque

190 CC

Bore 2.69 in. (68.3 mm)

Stroke 2.04 in. (51.8 mm)

Oil Capacity 18-20 fl. oz. (0.54 - 0.59 L)

• Kool Bore™ Aluminum alloy bore for cooler operation

• ReadyStart® provides easy no prime/no choke starting

• Certified to CARB Tier III and meets EPA 2012 Phase 3 Standards

• Large rewind starter reduces pullingeffort for easy starting

• Maintenance-free Magnetron® electronic ignition for quick, dependable starts

• Mechanical torque control for additional power

• Composite camshaft for quieter operation

• Commercial grade air cleaner with dual seals for longer engine life

• Large tube-outlet muffler reduces noise levels

• Overhead valve design (OHV) for cooler operation and longer valve life

• Buyer protection package provides two-year consumer engine warranty



125P02-0002-F1

Engine Specifications

SKU 125P02-0002-F1
Model/Type/Trim 125P02-0002-F1
Air Cleaner Dual Element
Alternator Without
Carburetor ReadyStart - Full System
Casing Clamp Without
Controls Fixed Speed
Crankshaft Straight 7/8" Dia - 3.156" PTO
Crankshaft Details 3/16" Keyway, 3/8-24 UNF-2B
Emissions Certification EVAP/EXH/EU
Engine Base Standard (Non Flange Mount)
Engine Package High Debris
Engine Sold In B&S Eng Replacement - USA/CAN
Engine Speed 3100 +/- 0100 RPM - No Load
Flywheel Light - Aluminum
Fuel Cap Black 1/4 Turn
Fuel Shutoff Without
Fuel Tank EVAP - 1.0L
Label Power 875 Professional Series,8.75TQ
Muffler Guard Stamped
Oil Dipstick Extended - Yellow Cap
Oil Drain Oil Drain/Fill Dipstick
Oil Filter Without
PTO Bearing Plain
Rewind Position 5:30
