Briggs & Stratton Vanguard OHV 6.5 HP 1"x 2-7/8" Shaft #12V332-0014

6.5hp Briggs Vanguard OHV
1" x 2-7/8" shaft, tapped 3/8" with 1/4" keyway.

Cast Iron Sleeve, Universal footprint for easy repowering.

Universal replacement engine for tillers, sprayers, compressors, blowers, power rakes, etc.

3 year warranty.

Model 12V332-0014.

39 lbs



Engine Oil Capacity: 20 fl. oz. (0.59 L)

Engine CC: 203 cc

Engine Bore: 2.68 in. (68.07 mm)

Stroke: 2.21 in. (56.13 mm)



FEATURES:

• Cyclonic air filter with 120% more dust holding capacity and 3x the filter life
• TransportGuard® Single fuel/ignition shut off system protects the engine from oil/fuel dilution during transport
• Commercial-style carburetor includes nickel plating to resist stale fuel deposit buildup
• CDI ignition with variable timing to optimize speed and torque
• Mechanical Governor
• Buyer protection package provides three-year commercial limited warranty

All power levels are stated gross horsepower at 3600 RPM per SAE J1940 as rated by Briggs & Stratton.

Crankshaft	596975
PTO Diameter	1 in.
Drilled Tapped	3/8-24
Keyway	1/4-Sq
Length	2-7/8
Starter Position	10:00
Controls	MF/R
Fuel Tank	3.2
Top Governor Speed	3600
Remote Stop	Yes
Manual Choke	Yes
Flange Mtg	Yes
Oil Sensor	Yes
